NOS
E-NOS (ETHERNEXION NETWORK OPERATING SYSTEM) UNIFIED SWTICH SOFTWARE FEATURES LIST
Overview
ENOS (Ethernexion Network Operating System): One OS, Infinite Possibilities.
At the heart of every Ethernexion switch—from 1G access to 800G AI cores—lies ENOS. This unified software platform represents over 10 years of rigorous commercial application and continuous refinement. Built on an advanced, modular, and hardware-decoupled architecture, ENOS provides the flexibility to adapt to any networking environment. With quarterly feature updates and proactive optimizations, we ensure your infrastructure doesn’t just keep up with the changing world—it stays ahead of it.
keywords
- Decade-Proven
- Modular Flexibility
- Agile Iteration
Features List table
- EB-Basic license
- MS- Advanced license
- ◯ - support
- X - nonsupport
| Type | Sub Type | Feature | Description | EB | MS | Remark |
|---|---|---|---|---|---|---|
| Ethernet basic features | Ethernet | Interface | Ethernet interface operating modes(full duplex, half duplex, and auto-negotiation) | ◯ | ◯ | |
| Ethernet interface operating rates | ◯ | ◯ | ||||
| Jumbo Frame | ◯ | ◯ | ||||
| port-xconnect | ◯ | ◯ | ||||
| Flow-control | Flow-control tx/rx | ◯ | ◯ | |||
| Storm-control | Port based storm-control | ◯ | ◯ | |||
| VLAN based storm-contro | ◯ | ◯ | ||||
| Port-block | Port-block(know/unknown unicast; know/unknown multicast/broadcast) | ◯ | ◯ | |||
| Port-isolate | L2/L3/All Port-isolate | ◯ | ◯ | |||
| Uni-direction isolate | ◯ | ◯ | ||||
| L2 Protocol Tunnel | L2 Protocol Tunnel(support CFM/DOT1X/SLOW-PROTO/STP | ◯ | ◯ | |||
| Forward mode | Store-and-forward | ◯ | ◯ | |||
| Cut-through | ◯ | ◯ | ||||
| VLAN | VLAN Access mode | Access/Trunk | ◯ | ◯ | ||
| Default VLAN | ◯ | ◯ | ||||
| VLAN Classification | VLAN Classification(port based/mac based/IP based/protocol based) | ◯ | ◯ | |||
| QinQ | Basic QinQ | ◯ | ◯ | |||
| Selective QinQ | ◯ | ◯ | ||||
| VLAN Mapping(1:1 VLAN Translation) | ◯ | ◯ | ||||
| VLAN Statistics | VLAN Statistics | ◯ | ◯ | |||
| Private VLAN | Private VLAN | ◯ | ◯ | |||
| Voice VLAN | Voice VLAN | ◯ | ◯ | |||
| Guest VLAN | Guest VLAN | ◯ | ◯ | |||
| MAC | MAC Address Table | Automatic learning and aging of MAC addresses | ◯ | ◯ | ||
| Hardware Learning | ◯ | ◯ | ||||
| Static and dynamic MAC address entries | ◯ | ◯ | ||||
| Blackhole MAC | ◯ | ◯ | ||||
| MAC Flapping detect | MAC Flapping detect | ◯ | ◯ | |||
| Port Bridge | Port Bridge | ◯ | ◯ |
